Features:
1.Die-cast aluminium body with baked epoxy powder coat finish for
durability and corrosion resistance
2. Toughened glass transparent cover with high light transmittance
3. Ultra-bright LED light source, service life is up to 50,000
hours
4. Designed with test buttons, convenient for regularly maintenance
5. The light fitting is designed with a main power indicator,
failure and charging indicator, to the using status
6. Designed with test button
This explosion proof led emergency light is perfect for both indoor
and outdoor use. Its 120° beam angle and long life span of over
50000 hours make it a reliable choice for any emergency situation.
With 2*3 W power and LED light source, this explosion proof
emergency light is sure to provide ample lighting when needed.
Technical Parameters:
| Ex Marking | Ex e IIC T6/ Ex tD A21 T80℃ | | Application | Zone 1, 2 & Zone 21, 22 | | IP Degree | IP65 | | Corrosion Resistant | WF1 | | Wattage | 1.5-3W | | Entries | G 3/4" Conduit Entry, Suitable for Φ10mm-Φ14mm cable | | Input Voltage | DC 110V;AC220V 50Hz | | Red Lettering | Optiional | | Back-up Battery | >120 min | | Weight | 3.25kg | | Mounting Styles | Pendant; Ceiling; wall |
| |
Applications:
A wide range of hazardous areas where ignitable vapors, dust,
moisture and corrosive elements are present
Areas requiring frequent on-and-off of lights or power cycling- no
warm up time required
| Typical applications include: |
| Oil and gas industries |
| Chemical, petrochemical |
| Pharmaceutical industries |
| Pulp and Paper |
| Waste and sewage treatment |
| Power Generation |
| Other high humidity, high dust, high temperature, vapor locations |
| Housing: | Die-casting aluminum |
| Exterior: | Stainless steel |
| Globe: | Tempered glass |
| Gasket: | Silicon rubber |
Customization:
CROWN EXTRA offers product customization services for their BCJ
model flameproof emergency light. This class 1 div 2 emergency
lighting equipment is made of durable aluminum alloy and has a
voltage of 220V. It has a power of 2*3W and a beam angle of 120°.
The product is certified by ATEX, CNEX, CERoHS, and ISO9001. The
minimum order quantity is 1pc and the price range is $20-$70. The
packaging details include 1 set/box and the delivery time is 5-9
work days. Payment terms include T/T and Western Union. The supply
ability is 5000pcs per month. This product can be wall-mounted and
is suitable for use as explosion proof emergency exit lights.
Support and Services:
The Flameproof Emergency Light product comes with the following
technical support and services:
- 24/7 technical support via phone or email
- On-site installation and maintenance services
- Access to online resources such as user manuals and
troubleshooting guides
- Warranty coverage for defects in materials and workmanship
- Replacement parts and accessories for purchase
